SCHNEIDER Modicon | TSX CAY41| Analog Input Module
Description
The TSX CAY41 is a 4-channel differential (or 8-channel single-ended) analog input module designed for the Modicon Premium automation platform. It provides high-resolution data acquisition from various sensors and transducers, supporting voltage, current, and thermocouple inputs with factory-calibrated accuracy and channel-to-channel isolation. The module ensures reliable signal processing and includes diagnostic LEDs for status indication.
Features
- High Resolution: 16-bit ADC.
- Input Channels: 4 differential or 8 single-ended.
- Input Types: Voltage (0...10 V, ±10 V), Current (0...20 mA, 4...20 mA), Thermocouples (J, K, T, E, R, S, B, N).
- Cold Junction Compensation: For thermocouple inputs.
- Isolation: Channel-to-channel and channel-to-ground isolation.
- Calibration: Factory-calibrated for accuracy.
- Diagnostic LEDs: For status indication.
- Operating Mode: Continuous or on-demand sampling.
Technical Specifications
- Input Channels: 4 differential or 8 single-ended.
- Resolution: 16 bits.
- Input Types: Voltage (0...10 V, ±10 V), Current (0...20 mA, 4...20 mA), Thermocouples (J, K, T, E, R, S, B, N).
- Accuracy: Voltage ±0.1% of full scale, Current ±0.1% of full scale, Thermocouples ±0.5°C or ±0.2% of full scale.
- Sampling Rate: Up to 100 samples per second per channel.
- Isolation: Channel-to-channel 500 V RMS, Channel-to-ground 500 V RMS.
- Cold Junction Compensation: For thermocouple inputs.
- Power Consumption: 30 mA at 24 V DC.
- Operating Temperature: -25°C to +70°C.
- Storage Temperature: -40°C to +85°C.
- Relative Humidity: 5% to 95% (non-condensing).
- Vibration: 10 to 500 Hz, 1.5 g.
- Shock: 15 g, 11 ms.
- Electrical Connections: 20-pin HE10 connector.
- Weight: 0.61 kg (1.34 lb).
- Dimensions: 102 x 95 x 120 mm (W x H x D).
